AX91378501WH- Axis Indoor Compact Intercom Monitor

  • 4.3″ display for video communication with visitors
  • Intuitive controls, even for inexperienced users
  • Designer surface made of tempered glass
  • Configuration via a web interface
  • HD Quality Sound with Noise Suppression
  • Display of date and time in sleep mode
  • Do not disturb mode
  • Parental lock activated via code
  • Dedicated lift-call button from the comfort of your apartment
  • Induction loop output for hearing impaired users
  • Switching between video from IP intercom and external IP camera
  • PoE for quick and easy installation

Flush installation box for this device needs to be ordered separately, please scroll down to accessories to order.

Compare
Brand: ,

Description

AX91378501WH- Axis Indoor Compact Intercom Monitor is an indoor answering unit designed especially for the residential market. Installation by connecting a single UTP cable and configuration via a web interface guarantees that integrators can put the unit into operation quickly and easily. Users will be impressed by the AX91378501WH- Axis Indoor Compact Intercom Monitor minimalist design, tempered glass surface, 4.3″ colour display and intuitive controls. A simply elegant solution for video communication.

Features

  • INTUITIVE CONTROLS, EVEN FOR INEXPERIENCED USERS
    Accepting calls, opening doors, displaying missed calls or switching to silent mode has never been easier. Large, colour backlit buttons make the interface intuitive and easy to operate.
  • DESIGNER SURFACE MADE OF TEMPERED GLASS
    The upper 3mm glass is chemically strengthened at 420°C in a salt bath, providing maximum durability and protecting it from scratches and impacts during everyday household use.
  • CONFIGURATION VIA A WEB INTERFACE
    Setting up all installed units, creating a directory and upgrading firmware can all be performed via the web interface, both from the local network and remotely using the Axis Remote Configuration service.
  • CONNECTION OF THE UNIT IN A MATTER OF SECONDS
    The structured cabling typical in houses today makes it possible to simply plug the Axis Indoor Compact straight into the system. Powering the device via PoE and communication are ensured immediately.

Technical Parameters

Power Supply
Type: 12V DC adapter or PoE 802.3af
Recommended power supply: 12V/1A
Reverse polarity protection: yes
User Interface
Controls: 7 capacitive buttons with RGB LED backlight
Display size: 4.3″ colour display
Resolution: 480x272px
Audio
Microphone: integrated
Speaker: integrated, 2W
Induction loop output: 600mV RMS
Codecs: G.711a/u, G.722, G.729, L16/16 kHz
Video
Codecs: H.264
Interface
LAN: 10/100BaseT, RJ-45
Recommended cabling: Cat5e or higher
Doorbell Input
Input type: switching contact (button/relay)
Contact type: normally open (NO)
Contact parameters: up to 50V/5mA, DC
Mechanical Parameters
Dimensions (W x H x D): 152 x 153 x 50mm
Weight: 387g
Operating temperature: 0 to 50°C
Relative operating humidity: 10 to 90% (non-condensing)
Storage temperature: -20 to 70°C
Recommended altitude: 0 to 2000m

Axis Indoor Compact Datasheet

Additional information

Weight 1 kg

Accessories

Flush Installation box

PoE switches & Injectors

Desk Stand

Downloads

2N Indoor Compact Datasheet
